Welcome to Pedro Charruadas´s web page

Welcome to Pedro Charruadas´s web page - eTec

SMT Senior Support Engineer

Certificated Engineer for the following SMT brands:

  • Assembléon
  • Yamaha
  • Speedline
  • Nutek
  • Cencorp
  • Pillarhouse


My key functions are installation and start-up of new production lines, training customers on user and maintenance level, production optimization & support installed base.

Based in Portugal and currently giving support to Iberica Region and occasionally Europe.

Working with several worldwide key account customers for the past 14 years.



iFlex by Assembleon

iFlex by Assembleon - eTec

An intelligent and flexible pick & place solution that fits to every PCB assembly need. Improving your line throughput by more than 30%, at almost zero defects!

Deliver the right quantities at the highest quality on time to your customers with iFlex: our new pick & place solution that brings Assembléon's unique quality levels to your growing product mix environment. Regardless the job size, iFlex handles your orders more efficiently than you have ever seen before. By planning and producing different board types on the same line. At low costs and at high yields.

  •
  •
  •

Available in three models (T4, T2 and H1), the modular iFlex lines are easy to install and (re)configure to handle all challenges in your production environment: dynamic product varieties and batch sizes with the increasing demand for quality and just-in-time deliveries.

  • iFlex T4 suits chip and small IC shooting (4 placement robots, placement speed of 51,000 cph, 128 twin tape feeder positions).
  • iFlex T2 is aimed at flexible placements (2 placement robots, placement speeds of 24,000 cph, 128 twin tape feeder positions).
  • iFlex H1 is for ICs and fine pitch placements (1 placement robot, placement speed of 7,100 cph, max 146 twin tape feeder positions/max 30 tray positions).

YG100R

YG100R - eTec

Modular Universal High-Precision High-Speed Mounter
  • High-speed mounting capacity handling 24,000CPH(0.15sec/CHIP Equivalent : optimum condition)
  • +/-50μm(CHIP), +/-30μm(QFP) mounting absolute accuracy in full time operation
  • Handles a wide range of components from 0402 chips to □45mm components and with long connectors
  • Capable of handling 15mm height components
  • Applicable to longer length PCB(up to L510mm)
